PVH Axial Piston Variable Medium Pressure Pump , Hydraulic Pumps
Introduction
PVH high flow, high performance pumps are a family of variable
displacement, inline piston units that incorporate the proven
design, quality manufacturing techniques and operating features of
other Vickers piston pumps, but in a smaller, lighter package.
The PVH series has been specially designed to meet the 250 bar
(3625 psi) continuous duty performance requirements of new
generation equipment designs.
These are efficient , reliable pumps, with a selection of optional
controls for maximum operational flexibility.
Designed specifically for strenuous application, they provide the
productivity gains and controllability improvements desired in
earthmoving, construction, machine tool, plastics, and all other
energy-conscious markets. As with all Vickers products, these pumps
have been fully laboratory tested and field proven.
PVH Series Benefits
Versatile design includes single pumps, thru-drive arrangements,
and a variety of drive shaft and control options that will adapt to
any application and provide the most cost effective installation.
Proven components designed into a heavy duty, compact housing to
provide 250 bar (3625 psi) continuous operating performance, and
280 bar (4050 psi) operating performance in a load sensing system.
This design assures long life at the higher performance levels
required of today’s power-dense machinery.
Compact and lightweight design to reduce the application weight,
and provide better access for installation and servicing.
Service kits developed for the most critical rotating and control
components to simplify and assure successful pump servicing.
Quiet designs available for noise-sensitive industrial
applications, reducing sound levels further to provide a more
acceptable environment.
Designed for maximum efficiency in any type of application. A
variety of compensators provide the most effective system control,
and the 95%-plus volumetric efficiency means more flow, and more
input energy, is directed to the work and not into heat and waste.
Heavy duty bearings and shafts result in minimum internal
deflections and wear, providing for longer life and maximum uptime.
