A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump

Guangdong MKS Hydraulic Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump from wholesalers

    Buy cheap A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump from wholesalers
    • Buy cheap A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump from wholesalers

    A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump

    Ask Lasest Price
    Supply Ability : 500pieces/Year
    Payment Terms : L/C, T/T, D/P, Western Union, Paypal, Money Gram
    Brand Name : Bosch Rexroth
    Model Number : A4vtg090hw100/33mrnc4V92f0000as-S
    Certification : GS, RoHS, CE, ISO9001
    Price : discussible
    Delivery Time : 5days
    • Product Details
    • Company Profile

    A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump

    A4vtg090hw100/33mrnc4V92f0000as-S Straight Shaft Swashplate Piston Type Hydraulic Pump

    Basic Info.

    Model NO.
    Rexroth
    After-sales Service
    Free Warranty
    Warranty
    Free Warranty
    Structure
    Axial Plunger Pump
    Cylinder Number
    Single Cylinder
    Drive Mode
    Mechanically Driven Pump
    Pump Shaft Position
    Horizontal
    Type
    V Type
    Power
    Electric
    Straight Shaft Swashplate Piston Type
    Pressureoil
    Radial Plunger Pump Type
    Valve with Flow
    A4vtg090ep4p0/33mrnc4c92f0000asx-S
    A4vtg090ep4p0/33mrnc4c92fa2s2as-0
    A4vtg090ep4p0/33mrnc4c92fa2s2asx-S
    A4vtg090ep4p0/33mrnc4V92fa2s2as-0
    A4vtg090ep4p0/33mrnc4V92fb2s4as-0
    A4vtg090ep4PT/33mrnc4c92f0000as-S
    A4vtg090hw100/33mlnc4c91f0000as-S
    A4vtg090hw100/33mlnc4c92f0000as-0
    A4vtg090hw100/33mlnc4c92f0000as-S
    A4vtg090hw100/33mlnc4V92fa2s2as-0
    A4vtg090hw100/33mrnc4c91f0000as-S
    A4vtg090hw100/33mrnc4c92f0000as-0
    A4vtg090hw100/33mrnc4c92f0000as-S
    A4vtg090hw100/33mrnc4c92f0000as-Y
    A4vtg090hw100/33mrnc4V82f0000as-S
    A4vtg090hw100/33mrnc4V82fa2s2as-S
    A4vtg090hw100/33mrnc4V92f0000as-0
    A4vtg090hw100/33mrnc4V92f0000as-S
    A4vtg090hw100/33mrnc4V92fa2s2as-0
    A4vtg090hw10t/33alnc4m93f0000af-0
    A4vtg090hw10t/33alnc4m93fa3s2af-0
    A4vtg090hw10t/33alnc4m93fa3s2as-0
    A4vtg090hw10t/33alnc4m94fa3s2ap-0
    A4vtg090hw10t/33arnc4m93fa3s2af-0
    A4vtg090hw10t/33arnc4m93fa3s2ap-0
    A4vtg090hw10t/33arnc4m93fa3s2as-0
    A4vtg090hw10t/33arnc4m94fa3s2ab-0
    A4vtg090hw10t/33arnc4m94fa3s2af-S
    A4vtg090hw10t/33arnc4m94fa3s2ap-0
    A4vtg090hw10t/33mrnc4V92f0000as-S
    Trademark
    MKS
    Transport Package
    Wooden Box
    Specification
    cast iron
    Origin
    China
    HS Code
    8413606090

    Product Description

    Technical data
    Series 33.
    Sizes NG71, 90.
    Nominal pressure 400 bar.
    Maximum pressure 450 bar.
    Closed circuit.
    For the drum drive in mobile concrete mixers.
    Features
    --Variable axial piston pump of swashplate design for hydrostatic drives in closed circuit
    --The flow is proportional to the drive speed and displacement.
    --The flow increases as the angle of the swashplate is adjusted from zero to its maximum value.
    --Flow direction changes smoothly when the swashplate is moved through the neutral position.
    --Two pressure-relief valves are provided on the high pressure ports to protect the hydrostatic transmission (pump and motor) from overload.
    --The high-pressure relief valves also function as boost valves.
    --The integrated boost pump acts as a feed pump and control pressure supply.
    --The maximum boost pressure is limited by a built-in boost pressure-relief valve.
    Table of values
    SizeNG7190
    Displacementvariable pumpVg maxcm37190
    boost pump (at p = 20 bar)Vg Spcm320.5 27
    Speedat Vg maxnnomrpm33003050
    minimumnminrpm500500
    Flow at nnom H and Vg maxqv maxl/min234275
    Power1) at nnom H, Vg max Dp = 400 barPmaxkW156183
    Torque1) at Vg max andDp = 400 barTmaxNm452573
    Dp = 100 barTNm113143
    Rotary stiffnessdrive shaft V8cNm/rad120900-
    drive shaft V9cNm/rad-150896
    Moment of inertia for rotary groupJGRkgm20.00970.0149
    Maximum angular accelerationarad/s22100018000
    Filling capacityVL1.31.2
    Mass approx. (without through drive)mkg5153
