    A11vo95drs/10r-NZD12K04 Hydraulic Open Circuit Pump For Heavy Duty Machinery

    Ask Lasest Price
    Supply Ability : 500pieces/Year
    Payment Terms : L/C, T/T, D/P, Western Union, Paypal, Money Gram
    Brand Name : Bosch Rexroth
    Model Number : A11vo95drs/10r-NZD12K04
    Certification : GS, RoHS, CE, ISO9001
    Price : discussible
    Delivery Time : 5days
    • Product Details
    • Company Profile

    A11vo95drs/10r-NZD12K04 Hydraulic Open Circuit Pump For Heavy Duty Machinery

    Powerful A11vo95drs/10r-NZD12K04 Hydraulic Open Circuit Pump for Heavy Duty Machinery

    Basic Info.

    Model NO.
    Rexroth
    After-sales Service
    Free Warranty
    Warranty
    Free Warranty
    Structure
    Axial Plunger Pump
    Cylinder Number
    Single Cylinder
    Drive Mode
    Mechanically Driven Pump
    Pump Shaft Position
    Horizontal
    Type
    V Type
    Power
    Electric
    Straight Shaft Swashplate Piston Type
    Pressureoil
    Radial Plunger Pump Type
    Valve with Flow
    A11vo95drs/10r-Nsd12K04
    A11vo95drs/10r-Nsd12K17
    A11vo95drs/10r-Nsd12K81
    A11vo95drs/10r-Nsd12K82
    A11vo95drs/10r-NZD12K02
    A11vo95drs/10r-NZD12K04
    A11vo95drs/10r-NZD12K61
    A11vo95drs/10r-NZD12K79
    A11vo95drs/10r-NZD12K82
    A11vo95drs/10r-Nsd12n00
    A11vo95drs/10r-NZD12K01
    A11vo95drs/10r-NZD12K02
    A11vo95drs/10r-NZD12n00
    A11vo95ep2/10L-NZD12n00p
    A11vo95ep2/10r-Npd12n00h
    A11vo95ep2/10r-NZD12n00h
    A11vo95ep2d/10L-NZD12K01h
    A11vo95ep2d/10L-NZD12K02p
    A11vo95ep2d/10L-NZD12K82p
    A11vo95ep2d/10r-Npd12n00h
    A11vo95ep2d/10r-NZD12K01h
    A11vo95ep2d/10r-NZD12K01p
    A11vo95ep2d/10r-NZD12K82p
    A11vo95ep2d/10r-NZD12n00p
    A11vo95ep2g/10r-NZD12K24p
    A11vo95ep2g/10r-NZD12n00h-S
    A11vo95HD1s/10r-Nsd12K01
    A11vo95HD2d/10r-NZD12K07
    A11vo95HD2d/10r-Nsd12K02
    A11vo95le2s/10r-Nsd12K01p
    Trademark
    MKS
    Transport Package
    Wooden Box
    Specification
    cast iron
    Origin
    China
    HS Code
    8413606090

    Product Description

    Technical data
    Series 1.
    Size NG40 to 260.
    Nominal pressure 350 bar.
    Maximum pressure 400 bar.
    Open circuit.
    Features
    - Variable axial piston pump of swashplate design for hydrostatic drives in open circuit hydraulic system.
    - Designed primarily for use in mobile applications.
    - The pump operates under self-priming conditions, with tank pressurization, or with an optional built-in charge pump (impeller).
    - A comprehensive range of control options is available matching any application requirement.
    - Power control option is externally adjustable, even when the pump is running.
    - The through drive is suitable for adding gear pumps and axial piston pumps up to the same, i.e. 100% through drive.
    - The output flow is proportional to the drive speed and infinitely variable between qV max and qV min = 0.
    Technical Data
    SizeA11VO40607595130145190260
    DisplacementVg maxcm34258.57493.5130145193260
    Vg mincm300000000
    Speed
    maximum at Vg max
    nmaxrpm30002700255023502100220021001800
    maximum at Vg £ Vg max 3)nmax1rpm35003250300027802500250021002300
    Flow
    at nmax and Vg max
    qv maxl/min126158189220273319405468
    Power at
    qv max and Δp = 350 bar
    PmaxkW7492110128159186236273
    Torque at
    Vg max and Δp = 350 bar
    TmaxNm23432641252172480810751448
    Rotary stiffnessZ shaftNm/rad88894102440145836199601302495302495346190686465
    P shaftNm/rad87467107888143104196435312403312403383292653835
    S shaftNm/rad5834786308101921173704236861236861259773352009
    T shaftNm/rad74476102440125603---301928567115
    Moment of inertia for rotary groupJTWkgm20.00480.00820.01150.01730.03180.03410.0550.0878
    Angular acceleration, max.arad/s22200017500150001300010500900068004800
    Filling capacityVl1.11.351.852.12.92.93.84.6
    Mass (approx.)mkg32404553667695125
    SizeA11VLO
    (with charge pump)
    130145190260
    DisplacementVg maxcm3130145193260
    Vg mincm30000
    Speed
    maximum at Vg max 2)
    nmaxrpm2500250025002300
    maximum at Vg £ Vg max 3)nmax1rpm2500250025002300
    Flow
    at nmax and Vg max
    qv maxl/min325363483598
    Power at
    qv max and Δp = 350 bar
    PmaxkW190211281349
    Torque at
    Vg max and Δp = 350 bar
    TmaxNm72480810751448
    Rotary stiffnessZ shaftNm/rad302495302495346190686465
    P shaftNm/rad312403312403383292653835
    S shaftNm/rad236861236861259773352009
    T shaftNm/rad--301928567115
    Moment of inertia for rotary groupJTRkgm20.03370.0360.05770.0895
    Angular acceleration, max. 4)arad/s210500900068004800
    Filling capacityVl2.92.93.84.6
    Mass (approx.)mkg7273104138
